3-354 Ellipse 3.5″ LED Ceiling Mount

Description

3-354 Ellipse 3.5″ LED Ceiling Mount

Features:

• Finish: Black, Polished Nickel, Satin Nickel
• Diffuser: White Opal Glass, Matte White Acrylic
• Plated steel and acrylic construction
• Delivered Lumen: Glass – 176 lm, Acrylic – 191 lm
• Color Temperature: 3000K
• CRI: 90
• Voltage: 120V to 277V
• Diffuser is 3.5 in diameter
• Approved for ceiling and wall mounted applications
• Cold rolled steel housing
• Driver mounts inside junction box
• Glass diffuser is 1/8″ matte opal
• Oxygen reserves the right to modify designs at any time
• Total luminaire power 7.1w
• Unit mounts a 4 octagonal junction box
• Unit requires 2.5″ deep junction box
• TRIAC and ELV dimming at 120V AC; 0-10V dimming, 100% to 10% current output

Lamping:

• 1 x 6.2W LED (Included)

Models:

3-354-115 , 3-354-120 , 3-354-124 , 3-354-215 , 3-354-220 , 3-354-224

Spec Sheet
